- General : L1 frequency, C/A code, 12 Parallel Channels
- Sensitivity :
-140dBm acquisition
-150 dBm tracking
- Update Rate : 1Hz
- Accuracy :
Position : 5m CEP
Velocity : 0.1m/sec
- Acquisition :
Cold start : < 50sec (typical)
Warm start : < 25sec (typical)
Hot start : < 10sec
- Reacquisition : <1 sec
- Dynamics :
Altitude : < 18,000m
Velocity : 515m/sec
Acceleration : 4g
- Operation Temperature : -40¢XC to + 85¢XC
- Storage Temperature : -55¢XC to + 90¢XC
- Operating Humidity : 5% to 95%
- Primary Power : 3.8V~8V DC
- Current Consumption : <38 mA
- Serial Interface : USB
- Protocol : NMEA-0183 v3.01 @ 4800 baud, 8-None-1
- Datum :
Default : WGS-84
Other : selectable for other Datum
- Antenna : On-Board Patch Antenna
- NMEA Messages : GGA, GLL, GSA, GSV, RMC, VTG, ZDA
- Dimension : 42 mm x 42 mm x 15.9mm (W x L x H)
|
|
