| Receiver Type: 12 channel / L1 frequency, C/A code |
| Position Accuracy: 5m CEP autonomous |
| Time to First Fix:<10sec Hot Start |
| <35sec Warm Start |
| <45sec Cold Start |
| Signal Reacquisition: < 1s |
| Sensitivity:-137dBm acquisition |
| -145dBm tracking |
| Dynamics: < 4G |
| Operational Limits:Altitude < 18,000m |
| Velocity < 500m/sec |
| Protocol: NMEA-0183; ver3.01 |
| 4800/9600 baud; 8 N 1 |
| Datum: Default WGS-84 (User definable) |
| Serial Interface: USB v1.1 |
| Connector:4P USB/M |
| Power Supply:5.0 V |
| Current Consumption: 110mA peak |
| 90mA nominal |
| Operating Temperature: -30¢XC ~ 70¢XC |
| Dimension: 66mm¡Ñ52mm¡Ñ23mm |
| Weight: <100g |
