The PCI-1800 series is a family of high performance data acquisition board for PC with PCI bus. It features a continuous, 330KHz for low gain (44KHz for high gain), gap-free data acquisition under DOS and Windows. The PCI-1800 family has the same architecture and has, two 12-bit D/A output channel, 16 digital input channels,16 digital output channels. The PCI-1800H,PCI-1800L provide 16 single-ended or 8 differential inputs. The PCI-1802H, PCI-1802L provide 32 single-ended or 16 differential inputs. The -H means high gain model and the -L means low gain model. The scan function of PCI-1800 is so amazing. We call it Magic Scan . The variable channel scan function is found in some famous data acquisition board . Compare to Variable channel scan, the Magic Scan improve a lot function and meet the demand of high end user. The Magic Scan  mechanism not only scan the different input channels at vastly different rates, but also at different gain. Even in multi-channel scan, the sampling rates can maintain at 330KS/s.

It is recommended to use PCI-1802L and PCI-1802H cards for multi-tasking environment, such as Windows and Linux. Which equips 8K samples hardware FIFO and reduces data overflow issues.

ICP DAS discontinue the /NDA model (without D/A function) since the standard model provides full functions that covers the requirement for /NDA version. Please contacts us for OEM/ODM project if you are interested on customized version (or /NDA model).
