Input voltage : 85Vac to 270Vac |
Input frequency : 47Hz to 63Hz |
Inrush current (Cold start) :
|
less than 30A at 115Vac |
less than 60A at 230Vac |
DC Outputs :
|
+24V/2.5A |
+5V/0.5A |
Efficiency : higher than 70% at rated load and 115Vac |
Holdup time : 16ms at rated load and 115Vac |
Over voltage protection : hiccup mode |
Short circuit protection : latch off |
Over voltage protection : latch off |
Operating temperature : 0 to 50 ¢XC |
Cooling : free air convection |
Storage temperature : -40 ¢XC to +85 ¢XC |
Dimensions : 210mm x 42mm x 116mm |
