The Ultimate in Performance: M-7017Z. (Modbus RTU protocol)     CHANNELS it is up to you to configure channels by the software from 10 differential channels into 20 single ended channels. INPUT TYPES & RANGE Both voltage and current are accepted. +/-150mV, +/-500mV, +/-1V, +/-5V,+/-10V. +/-20mA ,0~20mA, 4~20mA. JUST USER-FRIENDLY No external resistor needed for measuring the current, all you have to do is to open the shell first and finish the setting by jumper. Measuring the current is as simple as you think!   SAMPLING RATE The sampling rate of M-7017Z is changeable. There are fast mode and normal mode for your consideration. Fast Mode: 60Hz; Resolution:12 bit Normal Mode: 10Hz; Resolution: 16 bit PROTECTION The M-7017Z also passes 240Vrms over voltage protection for differential inputs and 150Vrms over voltage protection for singleended inputs, 3000VDC intra-module isolation, +/-4KV contact ESD protection, +/-4KV EFT protection for power, and +/-1KV EFT protection for RS-485.
